It is recommended to use D to set Display Current Layer Last = ON. D To open or close the current layer display, use method: input D from the keyboard to switch. Turn on or off the complementary display mode of the design screen. The method of use is: enter C to display on the keyboard, and then enter C to remove the display.
Global settings (Global Settings) C supplementary format, used in the design of inner negative film Thermal Plane and displaying the pad layer.
TURN OFF LAYERS IN PADS VIEWER FULL
PADS2007 modeless command and shortcut key D + O: Set the through-hole display mode P + O: Set the copper to display only the frame form L: Change the current layer (if the current layer is changed to the second layer, L2) Q: Measure, from Start measuring at the current position W: Change the line width G: Set the grid S: Find the component pin or component S (n) (n) Find the absolute coordinate point AA any angle, AD oblique angle, AO right angle: change the routing angle UN : Cancel the current operation RE: Repeat the operation multiple times Open: DRP, Close: DRO, ignore the design rules: DRI: Design rule check E: Suspend the traces without vias PL (n) (n): Lock the current operation layer pair VA: automatic via selection, select current via usage mode VP: buried or blind via VT: through-hole mode CTRL + W: full screen display CTRL + E: move CTRL + F: flip CTRL + I: flip CTRL + at any angle H: Highlight CTRL + Q: Query and modify CTRL + R: Flip at 45 degrees F2: Add trace F4: Lock layer pair F6: Select network F5: Select pin pair for modeless command in PowerPCB 5.0.1 1.
